Descripción
Difference between short shaft and long shaft of Engine:
# Short shaft: the shaft length is 381 mm (15 inches), which is suitable for ships with stern plate height of 44cm and below
# Long shaft: the shaft length is 508mm (20 inches), which is suitable for ships with stern plate height of 45cm-55cm
48V 3.6HP Electric Propeller Boat Motor–Short Shaft
1.Model:48V 3.6HP
2.Rated Power(W):800
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):18
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):13
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):420
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):95x42x29
16.N.W/G.W.(kgs):10.9/13.5
Notes:The Product does not contain the battery.
48V 3.6HP Electric Propeller Boat Motor–Long Shaft
1.Model:48V 3.6HP
2.Rated Power(W):800
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):18
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):13
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):518
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):108x42x29
16.N.W/G.W.(kgs):8.5/14
Notes:The Product does not contain the battery.
48V 4.0HP Electric Propeller Boat Motor–Short Shaft
1.Model:48V 4.0HP
2.Rated Power(W):1000
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):21
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):15
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):420
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):95x42x29
16.N.W/G.W.(kgs):10.9/13.5
Notes:The Product does not contain the battery.
48V 4.0HP Electric Propeller Boat Motor–Long Shaft
1.Model:48V 4.0HP
2.Rated Power(W):1000
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):21
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):15
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):518
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):108x42x29
16.N.W/G.W.(kgs):10.0/14.0
Notes:The Product does not contain the battery.
48V 5.0HP Electric Propeller Boat Motor–Short Shaft
1.Model:48V 5.0HP
2.Rated Power(W):1200
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):25
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):18
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):420
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):95x42x29
16.N.W/G.W.(kgs):12.0/14.0
Notes:The Product does not contain the battery.
48V 5.0HP Electric Propeller Boat Motor–Long Shaft
1.Model:48V 5.0HP
2.Rated Power(W):1200
3.Starting System:Accelerated Start
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):25
8.Gear Ratio:2.08(27:13)
9.Control System:Tiller Control
10.Maximum Speed(km/h):18
11.Recommended Propeller Range(in):7-1/4X5-A
12.Transom Plate Height(mm):518
14.Battery Model Recommendation:Selection 0f 30~120A Safe Storage Battery,Maximum Power Sustainable 2~8 Hours.
15.Packaging Size(cm):108x42x29
16.N.W/G.W.(kgs):12.5/15.5
Notes:The Product does not contain the battery.
12V ET45 Electric Propeller Boat Motor
1.Model:12V ET45
2.Thrust(kg):22
3.Speed control:F5-R2
4.Motor Type:Brush Motor
5.Rated Voltage(V):12
6.Rated Speed(r/min):1300
7.Rated Current(A):46
8.Rated Power(W):552
9.Control Handle:Telescopic Type
10.Maximum Speed(km/h):8
11.Maximum Rod Length(mm):760
12.Recommended Propeller Range(in):3 Leaves/10.6
13.Noise DB:50db
14.Battery Model Recommendation:Selection 0f 120A Safe Storage Battery,Maximum Power Sustainable 3 Hours.
15.Packaging Size(cm):107*55*18
16.N.W/G.W.(kgs):9/10
Notes:The Product does not contain the battery.
12V ET55 Electric Propeller Boat Motor
1.Model:12V ET55
2.Thrust(kg):27
3.Speed control:F5-R2
4.Motor Type:Brush Motor
5.Rated Voltage(V):12
6.Rated Speed(r/min):1370
7.Rated Current(A):50
8.Rated Power(W):600
9.Control Handle:Telescopic Type
10.Maximum Speed(km/h):10
11.Maximum Rod Length(mm):760
12.Recommended Propeller Range(in):3 Leaves/10.6
13.Noise DB:50db
14.Battery Model Recommendation:Selection 0f 120A Safe Storage Battery,Maximum Power Sustainable 2.8 Hours.
15.Packaging Size(cm):107*55*18
16.N.W/G.W.(kgs):10/11
Notes:The Product does not contain the battery.
12V ET65 Electric Propeller Boat Motor
1.Model:12V ET65
2.Thrust(kg):30
3.Speed control:F5-R2
4.Motor Type:Brush Motor
5.Rated Voltage(V):12
6.Rated Speed(r/min):1420
7.Rated Current(A):55
8.Rated Power(W):660
9.Control Handle:Telescopic Type
10.Maximum Speed(km/h):11
11.Maximum Rod Length(mm):760
12.Recommended Propeller Range(in):3 Leaves/10.6
13.Noise DB:50db
14.Battery Model Recommendation:Selection 0f 120A Safe Storage Battery,Maximum Power Sustainable 2.5 Hours.
15.Packaging Size(cm):107*55*18
16.N.W/G.W.(kgs):10/11
Notes:The Product does not contain the battery.
48V 7.0HP Electric Propeller Boat Motor
1.Model:48V 7.0HP
2.Rated Power(W):1800
3.Starting System:Switch Knob Added
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):45
8.Control System:Tiller Control
9.Manipulation Mode:Rear Operation
10.Rod Length(cm):91
11.Total Height(cm):132
12.Transom Plate Height(mm):381~508
14.Battery Model Recommendation:Choose Batteries With a Capacity of over 120AH.
15.N.W/G.W.(kgs):12/16
Notes:The Product does not contain the battery.
48V 8.0HP Electric Propeller Boat Motor
1.Model:48V 8.0HP
2.Rated Power(W):2200
3.Starting System:Switch Knob Added
4.Motor Type:Brushless Motor
5.Rated Voltage(V):48
6.Rated Speed(r/min):3000
7.Rated Current(A):50
8.Control System:Tiller Control
9.Manipulation Mode:Rear Operation
10.Rod Length(cm):91
11.Total Height(cm):132
12.Transom Plate Height(mm):381~508
14.Battery Model Recommendation:Choose Batteries With a Capacity of over 120AH.
15.N.W/G.W.(kgs):14/17
Notes:The Product does not contain the battery.
60V 10.0HP Electric Propeller Boat Motor
1.Model:60V 10.0HP
2.Rated Power(W):2200
3.Starting System:Switch Knob Added
4.Motor Type:Brushless Motor
5.Rated Voltage(V):60
6.Rated Speed(r/min):3000
7.Rated Current(A):38
8.Control System:Tiller Control
9.Manipulation Mode:Rear Operation
10.Rod Length(cm):91
11.Total Height(cm):132
12.Transom Plate Height(mm):381~508
14.Battery Model Recommendation:Choose Batteries With a Capacity of over 120AH.
15.N.W/G.W.(kgs):14/17
Notes:The Product does not contain the battery.
